Key Features
MH-FG-2000B is a heavy-duty automatic turntable pre-stretch pallet wrapping machine, specially designed for mass pallet cargo packaging in logistics warehouses, manufacturing factories and freight terminals.
- Material :
LLDPE stretch film - Color :
Yellow - Profile :
Power Supply ：Single Phase AC 110V/220V, 50/60Hz Rated Power ：1.25KW Max Turntable Load Capacity： 2000kg Turntable Diameter Standard Φ1500mm; Optional Φ1650mm / Φ1800mm Turntable Rotation Speed ：0~10r/min (stepless variable frequency adjustment) Standard Mast Height： 2400mm Optional 2000/2700/3000/3200/3400mm Max Effective Wrapping Height ：Mast height minus 400mm Applicable Wrapping Film ：LLDPE stretch film Allowed Film Size ：Film width ≤500mm; Film roll outer diameter ≤280mm; Standard 76mm film core Pre-stretch Ratio Optional ：150%/200%/250%/300%
MH-FG-2000B Pallet Wrapping Machine
MH-FG-2000B is a heavy-duty automatic turntable pre-stretch pallet wrapping machine, specially designed for mass pallet cargo packaging in logistics warehouses, manufacturing factories and freight terminals. Equipped with PLC intelligent control system and imported electrical components, it realizes fully programmable wrapping operations without manual film pulling. The powered pre-stretch film carriage stretches LLDPE film evenly to maximize film utilization, while the heavy-load turntable supports pallets up to 2000kg. It can automatically detect cargo height and customize wrapping cycles for bottom, middle and top layers, effectively fixing pallet goods, preventing collapse, dust and moisture damage during transportation. The machine complies with CE safety standards, runs stably under long-hour continuous working conditions and adapts to various harsh workshop environments.
DATASHEET
| Item | Technical Parameter |
|---|---|
| Model | MH-FG-2000B Automatic Pre-stretch Pallet Wrapper |
| Power Supply | Single Phase AC 110V/220V, 50/60Hz |
| Rated Power | 1.25KW |
| Max Turntable Load Capacity | 2000kg |
| Turntable Diameter | Standard Φ1500mm; Optional Φ1650mm / Φ1800mm |
| Turntable Rotation Speed | 0~10r/min (stepless variable frequency adjustment) |
| Standard Mast Height | 2400mm; Optional 2000/2700/3000/3200/3400mm |
| Max Effective Wrapping Height | Mast height minus 400mm |
| Applicable Wrapping Film | LLDPE stretch film |
| Allowed Film Size | Film width ≤500mm; Film roll outer diameter ≤280mm; Standard 76mm film core |
| Pre-stretch Ratio | Optional 150%/200%/250%/300% |
| Control System | Korean LG PLC + Chinese MEIWA LCD text display (Chinese & English switchable) |
| Main Imported Electric Parts | Schneider inverter, P+F photoelectric sensor, TE travel switch & connectors |
| Machine Overall Dimension | 2650mm × 1650mm × 800mm |
| Net Weight / Gross Weight | 750kg / 800kg |
| Working Noise | ≤75dB |
| Applicable Working Environment | Ambient temperature: -10℃ ~ 40℃; Humidity ≤98% (non-condensing) |
| Standard Accessories | Main machine, operation manual, installation tools |
| Optional Accessories | Loading ramp, external control box, electromagnetic film brake, extended mast |
ADVANTAGES
1. High Efficiency & Labor SavingFully automatic wrapping replaces manual operation. It greatly improves packaging speed and reduces
labor cost for pallet packaging.
2. Film Saving with Pre-stretch SystemEquipped with power pre-stretch function, the film stretching rate can reach up to 300%, effectively
reducing film consumption and packaging cost.
3. Stable & Safe OperationAdopts famous brand electric components and frequency conversion control. Soft start and soft stop avoid
cargo shaking or collapsing. Multiple safety protection ensures long-term stable running.
4. Intelligent & Easy OperationPLC control with automatic height sensing, auto-reset and adjustable wrapping layers. Chinese and English
dual-language panel, simple operation for all workers.
5. Heavy Load & Durable StructureReinforced steel frame and thickened turntable support max 2000kg load. Wear-resistant structure
ensures long service life for factory and warehouse heavy-duty use.
WHY YOU CHOOSE US?
1.Fully Customizable – We tailor products to your exact specs: size, color, material, and branding.
2.Proven Quality & Price – 21 years experience, strong financials, and consistent quality at competitive rates.
3.Fast Delivery – Efficient logistics ensure quick turnaround, including full container options.
4.Dedicated Support – We provide responsive after-sales service to ensure your satisfaction.
FAQ
1.What is kind of your business?
We are specialized in PET Strapping , Polypropylene（PP) Strap,Steel straps， high strength green banding, polyester fabric, PET /PP Strapping Buckles, plastic strip tapes, Fully/semi automatic strapping machine，Carton Sealing Machines, Battery/ Pneumatic strapping tools, strecth film, wrapping machine and etc.
2.How about your production time?
Some products in our stock, we can arrange delivery right away. Generally speaking, the consumable materials is about 7 workdays, pneumatic packing tools and battery packing tools is in our stock, big packing equipment should be around 20-30 workdays.
3.Are you trade company or factory?
We are a manufacturer with an export headquarters office and three branch factories for production.
4.How about the payment term?
TT, L/C is acceptable.
